Construction Drawing Packages:
Each plan set is drawn at 1/4"=1' scale and includes the following drawings:
Artist's Rendering: An artist's drawing of the home, usually viewed from the front, and general construction notes.
Elevations: Shows the front, sides, and rear, including exterior materials, trim sizes, roof pitches, etc.
Main Floor Plan: Shows placement and dimensions of walls, doors, & windows. Includes the location of appliances, plumbing fixtures, beams, ceiling heights, etc.
Second Floor Plan (if any): Shows the second floor in the same detail as the main floor. Includes second floor framing and details.
Foundation Plan: Shows the location of all concrete footings, floor beams, first floor framing, and foundation details. If there is a basement, a basement plan is included which shows all basement details.
Floor Framing Plan (if any): Shows location and spacing of floor joists and supporting walls or beams.
Roof Framing Plan: Shows roof outlines, conventional framing/trusses, beams, roof framing details, etc.
Section & Details: Shows a cross-section of the home. Shows support members, exterior and interior materials, insulation, and foundation. Specific details such as fireplaces, stairways, decks, etc. are drawn at 1/2" = 1' scale, and appear as needed throughout the prints.
Electrical Plan: A schematic layout of all lighting, switches and electrical outlets.
Concept Plan Packages:
Includes PDF and DWG files of the:
Floor Plan (s)
The concept plan package can save you valuable time and resources by providing the essentials of the design allowing for a local designer, architect, or engineer to complete the construction documents to the building practices, requirements, and site conditions in your area. Concept plans include an unlimited build license (non-transferable).
The Vista home plan is a lodge-style home design that truly lives up to its name. This richly windowed house plan is designed for a view lot. Whether that is a mountain, river, lake or rolling pastures nearly every room in the house can enjoy the view.
In addition to each major room having a window that faces the rear, the expansive wrap-around deck adds more space to enjoy the outdoors.
At the center of the Vista is a vaulted, hexagonal great room. Windows line three of the great room walls. The rear wall has two sets of sliding glass doors allowing the room to be open to the outdoors during warm, summer days. In the corner of the living room is a fireplace which will keep the Vista bright and warm when winter rolls around.
Open to the great room, the large kitchen provides a lot of counter space and cabinet storage. The open layout of the kitchen would allow multiple cooks to work in this space without getting in each other's way. Standing at the sink you can gaze out across the dining room to the panoramic view beyond. A raised, peninsular eating bar separates the kitchen from the dining space and makes a great spot to serve snacks while entertaining or quick weekday meals.
The owners' suite is separate from the other bedrooms in its own wing off the left side of the great room. Designed as a retreat the luxurious owners' suite has a private sitting area with fireplace and access to the back deck. A set of French doors open to the large walk-in closet and the owners' suite bathroom features dual sinks, oversized shower, and soaking tub. Glass blocks frame the soaking tub providing privacy along with natural light.
The other two bedrooms of this three bedroom home plan fill the wing to the right of the great room. Both bedrooms share a full bathroom with a combination tub/shower. At the end of this wing is the Vista's attached two car garage.
