Each plan set is drawn at 1/4"=1' scale and includes the following drawings:
Artist's Rendering: An artist's drawing of the home, usually viewed from the front, and general construction notes.
Elevations: Shows the front, sides, and rear, including exterior materials, trim sizes, roof pitches, etc.
Main Floor Plan: Shows placement and dimensions of walls, doors, & windows. Includes the location of appliances, plumbing fixtures, beams, ceiling heights, etc.
Second Floor Plan (if any): Shows the second floor in the same detail as the main floor. Includes second floor framing and details.
Foundation Plan: Shows the location of all concrete footings, floor beams, first floor framing, and foundation details. If there is a basement, a basement plan is included which shows all basement details.
Floor Framing Plan (if any): Shows location and spacing of floor joists and supporting walls or beams.
Roof Framing Plan: Shows roof outlines, conventional framing/trusses, beams, roof framing details, etc.
Section & Details: Shows a cross-section of the home. Shows support members, exterior and interior materials, insulation, and foundation. Specific details such as fireplaces, stairways, decks, etc. are drawn at 1/2" = 1' scale, and appear as needed throughout the prints.
Decorative gables and bold tapered columns add to the modern finishes of this Craftsman home plan. The Providence 5 is a one story home plan designed to take advantage of a corner lot with its side entry, attached two car garage.
Stepping through the front door, the foyer is designed as an air lock. A coat closet is to the right and another door that helps to regulate the interior temperature of the home is straight ahead. Through the airlock the floor plan opens up to a cozy great room.
The open concept living area has the living room towards the front of the home and naturally bright from windows along two walls. Centered along one of the walls is a fireplace that helps to keep the living room cozy during the cold winter months. Along the back of the living room is the kitchen and dining room.
The kitchen is well-appointed with modern appliances and ample work space. A center island provides some separation from the dining room and adds additional seating during larger gatherings. Along the back wall of the dining room is a sliding glass door leading out to the backyard. The ability to extend the living to the outdoors is up to the homeowner.
Along the kitchen a hallway leads pass a half bathroom, mechanical closet to the bedrooms. The master bedroom is the largest of the three with a wonderful view of the backyard. The shared bathroom is outfitted with dual vanities, toilet, soaking tub and shower. The bend in the hallway takes you to the laundry room and attached two car garage.
