Alternate crawl space and slab foundation available - call for quote.
General Notes and specifications, Such As:
a) Designs Loads
d) Structural Steel
g) Other Misc. specs.
Front, Rear and Side Elevations @1/4” scale
Foundation plan (1/4” scale) indicating beam and column sizes along with lower level framing
Reinforced foundation and footing details
First & Second Floor plan (1/4” scale) includes all necessary framing information, window rough openings, beam sizes and framing details for specialized areas.
Stairs, sections, cabinet layouts, window flashing and miscellaneous details necessary for understanding of construction methods.
Roof plan (1/8”) indicating pitches and wall heights as well as truss profiles indicating hell heights and raised ceiling areas
Wall section indicating standard materials and detailing for typical wall construction.
a) Floor joists
b) Exterior wall framing
c) Wall heights
Roof framing is indicated as manufactured engineered roof trusses. Truss profiles are included.
This lovely one-story home showcases a solid brick front with wood trim and arched window. The large Great Room, Dining and Kitchen areas open generously to create a spacious gathering space. The breakfast bar at the Kitchen provides expanded seating for quick meals or an oversized crowd. A Master Bedroom with private bath is set to the rear of the home and two additional bedrooms round out the first floor. An open staircase leads to a full basement that can be accessed for additional living space and a covered rear porch offers outdoor enjoyment.
