Each plan set is drawn at 1/4"=1' scale and includes the following drawings:
Artist's Rendering: An artist's drawing of the home, usually viewed from the front, and general construction notes.
Elevations: Shows the front, sides, and rear, including exterior materials, trim sizes, roof pitches, etc.
Main Floor Plan: Shows placement and dimensions of walls, doors, & windows. Includes the location of appliances, plumbing fixtures, beams, ceiling heights, etc.
Second Floor Plan (if any): Shows the second floor in the same detail as the main floor. Includes second floor framing and details.
Foundation Plan: Shows the location of all concrete footings, floor beams, first floor framing, and foundation details. If there is a basement, a basement plan is included which shows all basement details.
Floor Framing Plan (if any): Shows location and spacing of floor joists and supporting walls or beams.
Roof Framing Plan: Shows roof outlines, conventional framing/trusses, beams, roof framing details, etc.
Section & Details: Shows a cross-section of the home. Shows support members, exterior and interior materials, insulation, and foundation. Specific details such as fireplaces, stairways, decks, etc. are drawn at 1/2" = 1' scale, and appear as needed throughout the prints.
Simple yet eye-catching the Celeste 3 is a charming cottage home plan that is ideal for narrow urban lots or as a vacation home. The welcoming covered front porch extends the living space to the outdoors when the weather is nice.
Walking through the front door the floor plan opens up to an entry hallway. To the left is a coat closet and built-in bench. Straight ahead the hallway opens up providing three directions. Turning to the left at the end of the hall leads to the full bathroom which also houses the washer and dryer. Straight at the end of the hall, is the master suite. This comfortable retreat has direct access to the full bathroom along with an extra-long closet. Heading right, the floor plan opens up to the living area.
The kitchen is completely open to the living room. With counters and cabinets running along two walls, there is ample work and storage space in the kitchen. Designed as an eat-in kitchen the dining space is incorporated directly into the kitchen.
The living room is naturally bright from the large widow display along one wall. Stairs that run up the back lead to the second floor.
While the Celeste 3 is designed as a two story home plan, the second floor is completely unfinished. This allows the homeowner to complete this space to their specifications, whether that is an additional bedroom, a bathroom, hobby space or additional gathering space.
Back on the main floor another set of stairs leads to the basement foundation. Like the second floor, the basement is unfinished proving homeowners’ with space to grow.
