This charming Craftsman garage plan can store 2 cars or 4 if stacked two deep. Both garage doors are the same size at 9' wide and 10' tall. Towards the back of the garage is a work bench with sink and storage tucked under the stairs that lead up to the loft. The loft could function as a recreation room, craft room or whatever else you need it to be. Along one of the walls is space for a future counter with sink and small refrigerator.
Photographs may show modifications made to plans. Copyright owned by designer.
- At a glance
- 1734 Square Feet
- 2 Floors
- 2 Car Garage
- More about the plan
- Pricing
- Basic Details
- Building Details
- Interior Details
- Garage Details
- See All Details
