Construction Drawing Packages:
Each plan set is drawn at 1/4"=1' scale and includes the following drawings:
Artist's Rendering: An artist's drawing of the home, usually viewed from the front, and general construction notes.
Elevations: Shows the front, sides, and rear, including exterior materials, trim sizes, roof pitches, etc.
Main Floor Plan: Shows placement and dimensions of walls, doors, & windows. Includes the location of appliances, plumbing fixtures, beams, ceiling heights, etc.
Second Floor Plan (if any): Shows the second floor in the same detail as the main floor. Includes second floor framing and details.
Foundation Plan: Shows the location of all concrete footings, floor beams, first floor framing, and foundation details. If there is a basement, a basement plan is included which shows all basement details.
Floor Framing Plan (if any): Shows location and spacing of floor joists and supporting walls or beams.
Roof Framing Plan: Shows roof outlines, conventional framing/trusses, beams, roof framing details, etc.
Section & Details: Shows a cross-section of the home. Shows support members, exterior and interior materials, insulation, and foundation. Specific details such as fireplaces, stairways, decks, etc. are drawn at 1/2" = 1' scale, and appear as needed throughout the prints.
Electrical Plan: A schematic layout of all lighting, switches and electrical outlets.
Concept Plan Packages:
Includes PDF and DWG files of the:
Floor Plan (s)
The concept plan package can save you valuable time and resources by providing the essentials of the design allowing for a local designer, architect, or engineer to complete the construction documents to the building practices, requirements, and site conditions in your area. Concept plans include an unlimited build license (non-transferable).
There is plenty to appreciate about the Atkinson plan. A welcoming porch wraps around three sides of this spacious country-style farmhouse.
The large kitchen is at the core of this home and is both open and enlosed. From the kitchen sink you can gaze into the great room, while food preparation and clutter is out of site of guests in the dining and great room. The center island is home to the cooktop and has a raised eating bar on one end.
The nook is brightened by windows on three sides and a French door opens onto a covered patio that connects the home to the garage and office. The office could also function as a hobby room or workshop.
In the great room, the two story ceiling creates a sense of spaciousness. Two sets of French doors flank the fireplace that is capped by a clerestory window that allows the room to fill with natural light. Double doors lead into the owners' suite. Amenities here include a large bathroom with a spa tub, double vanity, private toilet, glass block shower and a walk-in closet.
On the second level, a wrap around balcony looks over the great room below. The two bedrooms are connected by a jack-n-jll bathroom and have plenty of closet space. The bedroom to the rear of the home has a window seat situated between two closets.
