Construction Drawing Packages:
Each plan set is drawn at 1/4"=1' scale and includes the following drawings:
Artist's Rendering: An artist's drawing of the home, usually viewed from the front, and general construction notes.
Elevations: Shows the front, sides, and rear, including exterior materials, trim sizes, roof pitches, etc.
Main Floor Plan: Shows placement and dimensions of walls, doors, & windows. Includes the location of appliances, plumbing fixtures, beams, ceiling heights, etc.
Second Floor Plan (if any): Shows the second floor in the same detail as the main floor. Includes second floor framing and details.
Foundation Plan: Shows the location of all concrete footings, floor beams, first floor framing, and foundation details. If there is a basement, a basement plan is included which shows all basement details.
Floor Framing Plan (if any): Shows location and spacing of floor joists and supporting walls or beams.
Roof Framing Plan: Shows roof outlines, conventional framing/trusses, beams, roof framing details, etc.
Section & Details: Shows a cross-section of the home. Shows support members, exterior and interior materials, insulation, and foundation. Specific details such as fireplaces, stairways, decks, etc. are drawn at 1/2" = 1' scale, and appear as needed throughout the prints.
Electrical Plan: A schematic layout of all lighting, switches and electrical outlets.
Concept Plan Packages:
Includes PDF and DWG files of the:
Floor Plan (s)
The concept plan package can save you valuable time and resources by providing the essentials of the design allowing for a local designer, architect, or engineer to complete the construction documents to the building practices, requirements, and site conditions in your area. Concept plans include an unlimited build license (non-transferable).
New to plan buying?
A simple low pitch room and batt and board siding give the Sahalie a distinct prairie style. The L-shaped covered porch provides ample space for outdoor living. The entry is completely open to the great room. The great room is a trending design feature and its informal nature allows for people and conversations to flow freely between the living room, dining room, and kitchen. An island with raised eating bar in the kitchen helps to provide some visual separation while adding to the available seating. The right side of this three-bedroom house plan contains two of the secondary bedrooms with a full bathroom nestled in between. If the additional bedrooms are not needed these rooms provided excellent flexibility and could be furnished as an exercise/meditation room, craft room, guest accommodations, or whatever else suites. Along the back of the floor plan is the owners' suite with a private bathroom and generous-sized walk-in closet. In the center of the home is the laundry room which is just a few steps away from the attached two car garage and basement access stairs. The basement foundation is unfinished allowing it to be completed at a later date. Optionally this home can be constructed on a sloped lot with the walk-out basement variation. This option allows the Sahalie to fit neatly on a side sloping lot.
