Basement Ceiling Height: 8'-0"
Each plan set is drawn at 1/4"=1' scale and includes the following drawings:
Artist's Rendering: An artist's drawing of the home, usually viewed from the front, and general construction notes.
Elevations: Shows the front, sides, and rear, including exterior materials, trim sizes, roof pitches, etc.
Main Floor Plan: Shows placement and dimensions of walls, doors, & windows. Includes the location of appliances, plumbing fixtures, beams, ceiling heights, etc.
Second Floor Plan (if any): Shows the second floor in the same detail as the main floor. Includes second floor framing and details.
Foundation Plan: Shows the location of all concrete footings, floor beams, first floor framing, and foundation details. If there is a basement, a basement plan is included which shows all basement details.
Floor Framing Plan (if any): Shows location and spacing of floor joists and supporting walls or beams.
Roof Framing Plan: Shows roof outlines, conventional framing/trusses, beams, roof framing details, etc.
Section & Details: Shows a cross-section of the home. Shows support members, exterior and interior materials, insulation, and foundation. Specific details such as fireplaces, stairways, decks, etc. are drawn at 1/2" = 1' scale, and appear as needed throughout the prints.
New to plan buying?
A trio of textures creates an inviting look to the farmhouse plan Duluth. Just a few steps up from the street level the double front door is welcoming while filling the entry with natural light. Inside the foyer is designed as an airlock allowing the space to be closed off from the main living area. To the right, there is space for a bench. Through the double pocket doors is a short hallway. A barn door slides to reveal a mudroom which is also conveniently located near the attached one-car garage. To the left, the floor plan opens up to the great room. Living, dining, and kitchen are all once seamless space. The living room is richly windowed and features a fireplace along the front wall allowing it to be enjoyed throughout the great room. Towards the rear of the home is the dining room which offers access to the covered terrace through a sliding glass door. The kitchen is separated from the dining room by a long island with an eating bar. Bedrooms fill the back right corner of the floor plan. The master suite is a cozy retreat and offers a walk-in closet and private bathroom. The one-story design is ideal for a narrow lot at only 42' wide.
