Each plan set is drawn at 1/4"=1' scale and includes the following drawings:
Artist's Rendering: An artist's drawing of the home, usually viewed from the front, and general construction notes.
Elevations: Shows the front, sides, and rear, including exterior materials, trim sizes, roof pitches, etc.
Main Floor Plan: Shows placement and dimensions of walls, doors, & windows. Includes the location of appliances, plumbing fixtures, beams, ceiling heights, etc.
Second Floor Plan (if any): Shows the second floor in the same detail as the main floor. Includes second floor framing and details.
Foundation Plan: Shows the location of all concrete footings, floor beams, first floor framing, and foundation details. If there is a basement, a basement plan is included which shows all basement details.
Floor Framing Plan (if any): Shows location and spacing of floor joists and supporting walls or beams.
Roof Framing Plan: Shows roof outlines, conventional framing/trusses, beams, roof framing details, etc.
Section & Details: Shows a cross-section of the home. Shows support members, exterior and interior materials, insulation, and foundation. Specific details such as fireplaces, stairways, decks, etc. are drawn at 1/2" = 1' scale, and appear as needed throughout the prints.
Eye-catching vertical lines, stone façade and exposed beam accent in the gable blend together to create a stunning exterior to the Urban Valley 2, a one story Craftsman house plan. This small house plan is just as well suited for a narrow urban lot or sprawling rural property.
Stepping through the front door, the floor plan opens up to a split level design. At the foyer level a coat closet is to the left and access to the attached one car garage is to the right. Straight ahead are two sets of stairs.
Following the stairs to the right takes you to the basement level. While this space is unfinished, the homeowner can tailor the completion of this space to their needs and lifestyle. A suggested layout for the basement provides three additional bedrooms to this two bedroom home plan along with a full bathroom, extra storage and expanded living area.
Back at the foyer the stairs to the left lead up to the main living area. Immediately to the right is a bedroom that is naturally bright from windows along the front wall. Continuing down the hall the floor plan opens up to a great room.
The kitchen is generously sized for a home of this size and provides ample counter space and cabinet storage. Acting as a visual barrier between the kitchen and the dining room is an island complete with eating bar. This space is great for serving up quick week day meals or serving up snacks during larger parties.
Along the back of the great room are the dining and living rooms. The dining room has a sliding glass door providing access to the back yard. Through the living room a hallway leads to another bedroom. This one is slightly larger and could serve as the master bedroom as it boasts a walk-in closet.
Across from the bedroom is a full bathroom that is shared with the rest of the main floor. This large bathroom contains the washer and dryer and boasts a separate shower, soaking tub and single vanity.
