General Notes and specifications, Such As:
a) Designs Loads
d) Structural Steel
g) Other Misc. specs.
Front, Rear and Side Elevations @1/4” scale
Foundation plan (1/4” scale) indicating beam and column sizes along with lower level framing
Reinforced foundation and footing details
First & Second Floor plan (1/4” scale) includes all necessary framing information, window rough openings, beam sizes and framing details for specialized areas.
Stairs, sections, cabinet layouts, window flashing and miscellaneous details necessary for understanding of construction methods.
Roof plan (1/8”) indicating pitches and wall heights as well as truss profiles indicating hell heights and raised ceiling areas
Wall section indicating standard materials and detailing for typical wall construction.
a) Floor joists
b) Exterior wall framing
c) Wall heights
Roof framing is indicated as manufactured engineered roof trusses. Truss profiles are included.
New to plan buying?
A covered porch creates a warm and inviting exterior to this charming one level home. Split bedrooms, sloped ceilings a gas fireplace and an open Great Room and Kitchen set the stage for a home that is dedicated to casual lifestyle. Double sliding doors across the rear of the Great Room create a wonderful indoor/outdoor relationship. The Master Bedroom with private Bath and walk-in closet also enjoys a view to the rear yard and a full walk-out basement foundation makes this the perfect fit for a lakefront or mountain view setting
