Construction Drawing Packages:
Each plan set is drawn at 1/4"=1' scale and includes the following drawings:
Artist's Rendering: An artist's drawing of the home, usually viewed from the front, and general construction notes.
Elevations: Shows the front, sides, and rear, including exterior materials, trim sizes, roof pitches, etc.
Main Floor Plan: Shows placement and dimensions of walls, doors, & windows. Includes the location of appliances, plumbing fixtures, beams, ceiling heights, etc.
Second Floor Plan (if any): Shows the second floor in the same detail as the main floor. Includes second floor framing and details.
Foundation Plan: Shows the location of all concrete footings, floor beams, first floor framing, and foundation details. If there is a basement, a basement plan is included which shows all basement details.
Floor Framing Plan (if any): Shows location and spacing of floor joists and supporting walls or beams.
Roof Framing Plan: Shows roof outlines, conventional framing/trusses, beams, roof framing details, etc.
Section & Details: Shows a cross-section of the home. Shows support members, exterior and interior materials, insulation, and foundation. Specific details such as fireplaces, stairways, decks, etc. are drawn at 1/2" = 1' scale, and appear as needed throughout the prints.
Electrical Plan: A schematic layout of all lighting, switches and electrical outlets.
Concept Plan Packages:
Includes PDF and DWG files of the:
Floor Plan (s)
The concept plan package can save you valuable time and resources by providing the essentials of the design allowing for a local designer, architect, or engineer to complete the construction documents to the building practices, requirements, and site conditions in your area. Concept plans include an unlimited build license (non-transferable).
A-Frame house plan, the Chinook, is a vacation cottage with a large bay of windows that enable you to take in the natural surroundings. This rustic cabin offers approximately 1200 square feet of living space.
While the log exterior lends to the rustic look this design is also available in 2x6 conventional construction. The metal roof and ample windows add a contemporary feel to this design. Along with the attractiveness, the metal roof gives extra protection to the home in case of fire.
The four-high stacked windows provide lots of natural light, even on an overcast day. This area is open to the second floor and a sliding glass door provides access to a large deck that spans the rear exterior.
A wood stove located in the front corner provides fuel efficient heating on chilly days, in any season.
The galley kitchen is larger than you would expect in a home of this size. The refrigerator, stove, dishwasher, and sink are efficiently placed and an eating bar provides additional counter space. The utility room is close by, hidden behind folding doors in a hallway that leads outside.
Upstairs, is a large loft, and a bunk room. Attic storage is available on either side of this room, as well as to the right of the loft. This storage room is large enough to be used as additional living space if need be.
