Garage - 74466

Associated Designs

$0.00
(No reviews yet) Write a Review
SKU:
101 - 20-442
Plan Number:
74466
Pricing Set Title:
Garage CAT 3
Designer Plan Title:
20-442
Date Added:
11/04/2022
Date Modified:
01/25/2024
Designer:
info@associateddesigns.com; jessica@associateddesigns.com
Plan Name:
Garage
Note Plan Packages: PDF Print Package:
Best Value!
Note Plan Packages: Plans Now:
PDF Download!
Family Plan:
20-049
Structure Type:
Garage
Best Seller (Rank #):
10000
Square Footage: Total Living:
1579
Square Footage: Garage:
1008
Square Footage: Craft Room:
571
Floors:
2
FLOORS_filter:
2
Ridge Height:
21'10"
Overall Exterior Depth:
28
Overall Exterior Width:
36
Main Floor Ceiling Height:
9'
Second Floor Ceiling Height:
8'
Available Foundations:
Concrete Slab
Default Foundation:
Concrete Slab
Available Walls:
2x6 Wood Frame
Default Wall:
2x6 Wood Frame
Ext Wall Material:
Siding, Shingles
Lot Slope:
Level Lot
Roof Framing:
Combination Stick/Truss
Snow Roof Load:
25.00
Roof Pitch:
8/12
Primary Style:
Cottage
Secondary Styles:
Country
Secondary Styles:
Traditional
Garage Orientation:
Front Entry
Garage Bays Min:
3
Garage Bays Max:
3
GARAGE BAYS_filter:
3
Garage Features:
Recreation Room
Styles:
Cottage House Plans
Styles:
Country House Plans
Styles:
Traditional House Plans
Collections:
2 Story House Plans
Collections:
Garage, Garage w/Living, Carports
Collections:
Small House Plans
Product Rank:
5468
Note Plan Packages: Master Builder CAD Set:
Unlimited Builds!
Creation Date:
11/2022
Plan SKU:
20-442
Max Price:
1100.00
Min Price:
350.00

Shingle accents give this three-car detached garage plan a cottage feel. Each of the roll up doors are 9' (w) x 8' (t). Along the back a set of stairs leads up to the craft room. An 8' ceiling runs down the middle and slopes down to half-height walls.
