This traditional style garage plan features a three-stall front exterior with 9' x 7' overhead doors. Inside there is plenty of space for the car enthusiast or busy family. Upstairs is a fully equipped living space with full kitchen, living room, two bedrooms, and a full bath. This could be used as a guest house, rental, or a temporary living structure while remodeling a larger house.
Plan 92241
Photographs may show modifications made to plans. Copyright owned by designer.
- At a glance
-
1128 Square Feet
-
2 Bedrooms
-
1 Full Baths
-
2 Floors
-
3 Car Garage
- More about the plan
- Basic Details
- Building Details
- Interior Details
- Garage Details
- See All Details
Plan details
Basic Details
Building Details
Interior Details
Garage
What's Included in a Plan Set?
Elevations: Shows the front, sides, and rear, including exterior materials, trim sizes, roof pitches, etc.
Main Floor Plan: Shows placement and dimensions of walls, doors, & windows. Includes the location of appliances, plumbing fixtures, beams, ceiling heights, etc.
Second Floor Plan (if any): Shows the second floor in the same detail as the main floor. Includes second floor framing and details.
Foundation Plan: Shows the location of all concrete footings, floor beams, first floor framing, and foundation details. If there is a basement, a basement plan is included which shows all basement details.
Details show the size, direction and spacing of all floor joists, ceiling joists, and rafters or roof trusses.
Roof Framing Plan: Shows roof outlines, conventional framing/trusses, beams, roof framing details, etc.
Section & Details: Shows a cross-section of the home. Shows support members, exterior and interior materials, insulation, and foundation. Specific details such as fireplaces, stairways, decks, etc. appear as needed throughout the prints.
Electrical Plan: A schematic layout of all lighting, switches and electrical outlets.
New to Plan Buying?
92241
Residential Design Services
$0.00
- SKU:
- 118 - 2808
- Plan Number:
- 92241
- Pricing Set Title:
- 1-4
- Designer Plan Title:
- 2808
- Date Added:
- 04/17/2019
- Date Modified:
- 01/21/2023
- Designer:
- mike@rdshomeplans.com
- Structure Type:
- Garage
- Best Seller (Rank #):
- 10000
- Square Footage: Total Living:
- 1128
- Square Footage: Garage:
- 988
- Square Footage: 2nd Floor:
- 1128
- Floors:
- 2
- FLOORS_filter:
- 2
- Bedrooms:
- 2
- BEDROOMS_filter:
- 2
- Baths Full:
- 1
- FULL BATHROOMS_filter:
- 1
- Baths Half:
- 0
- Ridge Height:
- 26'
- Overall Exterior Depth:
- 28
- Overall Exterior Width:
- 42
- Main Floor Ceiling Height:
- 8'
- Second Floor Ceiling Height:
- 8'
- Available Foundations:
- Concrete Slab
- Default Foundation:
- Concrete Slab
- Available Walls:
- 2x4 Wood Frame
- Available Walls:
- 2x6 Wood Frame
- Default Wall:
- 2x4 Wood Frame
- Ext Wall Material:
- Siding
- Lot Slope:
- Level Lot
- Roof Framing:
- Truss
- Snow Roof Load:
- 30.00
- Roof Pitch:
- 7/12
- Primary Style:
- Traditional
- Secondary Styles:
- Cape Cod
- Collections:
- Accessory Structures
- Interior Features:
- Great Room
- Utility Room Features:
- Close to Kitchen or Garage
- Utility Room Features:
- Second Floor Utility Room
- Garage Orientation:
- Front Entry
- Garage Bays Min:
- 3
- Garage Bays Max:
- 3
- GARAGE BAYS_filter:
- 3
- Garage Features:
- w/Living Space
- Family Plan:
- 2301
- Styles:
- Traditional House Plans
- Styles:
- Cape Cod House Plans
- Collections:
- 2 Story House Plans
- Collections:
- Garage, Garage w/Living, Carports
- Collections:
- Small House Plans
- Product Rank:
- 1416
