Additional Ceiling Heights:
Sun Room: 11'
Great Room: 18'
Each plan set is drawn at 1/4"=1' scale and includes the following drawings:
Front Rendering: A rendering of the front elevation along with general construction notes.
Elevations: Shows the front, sides, and rear, including wall and window heights, exterior materials, soffit heights, roof pitches, etc.
Main Floor Plan: Shows placement and dimensions of walls, doors, & windows. Includes the location of appliances, plumbing fixtures, roof, wall, and floor structure from above (if any), ceiling heights, etc.
Second Floor Plan (if any): Shows the second floor in the same detail as the main floor. Includes second floor roof structure as well.
Foundation Plan: Shows the location of all concrete walls and footings, beams supporting the floor structure and structure above, and foundation details. If there is a basement, a basement plan is included which shows all basement details.
Roof Plan: Shows roof outlines, lines of bearing walls below, roof framing details, etc.
Section & Details: Shows a cross-section of the home. Shows support members, exterior and interior materials, insulation, and foundation. Stairway, kitchen elevations, and wall section details are drawn at 1/2" = 1' scale, and appear as needed throughout the prints.
Electrical Plan: A schematic layout of all lighting, switches and electrical outlets drawn at 1/8" = 1'. Electrical general notes are provided as well.
New to plan buying?
This Eurpopean home plan blends stone and shake siding that creates classic curb appeal. The great room, kitchen and dining room flow together to create an open floor plan that is spacious for entertaining. The open two story ceiling of the great room and kitchen adds to the sense of spaciousness. The master bedroom suite opens onto the sunroom and features include a dual vanity, private toilet, extra large shower, and walk-in closet. On the second level, the balcony overlooks the main floor and you will find two additional bedrooms. The daylight basement includes a large family room with a wet bar and wine cellar, game room, theater, and an additional bedroom.
