General Notes and specifications, Such As:
a) Designs Loads
d) Structural Steel
g) Other Misc. specs.
Front, Rear and Side Elevations @1/4” scale
Foundation plan (1/4” scale) indicating beam and column sizes along with lower level framing
Reinforced foundation and footing details
First & Second Floor plan (1/4” scale) includes all necessary framing information, window rough openings, beam sizes and framing details for specialized areas.
Stairs, sections, cabinet layouts, window flashing and miscellaneous details necessary for understanding of construction methods.
Roof plan (1/8”) indicating pitches and wall heights as well as truss profiles indicating hell heights and raised ceiling areas
Wall section indicating standard materials and detailing for typical wall construction.
a) Floor joists
b) Exterior wall framing
c) Wall heights
Roof framing is indicated as manufactured engineered roof trusses. Truss profiles are included.
New to plan buying?
An exciting exterior with stone, siding and shakes, boxed windows and wood trim create a beautiful curb appeal. Beamed ceilings and a ceiling height of 12' top the Great Room and open Dining Room concept. The foyer showcases a two story entry opening it to the second floor, and the Kitchen enjoys an island with seating for an overflow crowd. The Master Bedroom Suite features a double bowl vanity, shower and commode room. The Master Closet opens to the bath and to the Laundry room for convenience and the Mud Room creates an orderly entry from the garage with cubbies, closet and Powder Room. The upper level boasts three secondary bedrooms one sharing a Jack & Jill bath and the third enjoys a private bath and walk-in closet for an inviting guest suite.
