Each plan set is drawn at 1/4"=1' scale and includes the following drawings:
Artist's Rendering: An artist's drawing of the home, usually viewed from the front, and general construction notes.
Elevations: Shows the front, sides, and rear, including exterior materials, trim sizes, roof pitches, etc.
Main Floor Plan: Shows placement and dimensions of walls, doors, & windows. Includes the location of appliances, plumbing fixtures, beams, ceiling heights, etc.
Second Floor Plan (if any): Shows the second floor in the same detail as the main floor. Includes second floor framing and details.
Foundation Plan: Shows the location of all concrete footings, floor beams, first floor framing, and foundation details. If there is a basement, a basement plan is included which shows all basement details.
Floor Framing Plan (if any): Shows location and spacing of floor joists and supporting walls or beams.
Roof Framing Plan: Shows roof outlines, conventional framing/trusses, beams, roof framing details, etc.
Section & Details: Shows a cross-section of the home. Shows support members, exterior and interior materials, insulation, and foundation. Specific details such as fireplaces, stairways, decks, etc. are drawn at 1/2" = 1' scale, and appear as needed throughout the prints.
New to plan buying?
Inspired by the sunny climate of the Mediterranean, ranch house plan the Clarendon is bright inside and out. A smooth stucco exterior is accent by stone, inviting a second look.
Framed by bold stone columns, the front door opens to the foyer. Just offset from the larger family room which is window rich and features a fireplace surrounded by built-ins. Partial walls and columns separate the more formal living room from the formal dining room and informal great room.
Towards the front of the home is the formal dining room, ideal for entertaining or important family gatherings. An opening along the back wall connects the dining room with the kitchen.
The spacious kitchen is well-appointed and in addition to modern appliances features a breakfast nook and island with eating bar. Nearby is a walk-in pantry along with the laundry room. The pass-through configuration of the laundry room allows it to function as a mudroom between the attached two car garage and the main living area. Towards the back of the kitchen, the rest of the great room is filled with an informal family room. This window rich space also has a sliding glass door that leads to the screened porch.
The sleeping areas of this three bedroom house plan are separated and frame the gathering spaces. On the left side of the floor plan is the master suite. Accessed through a set of French doors off the formal living room, the master bedroom is naturally illuminated from windows on three of the walls. One of the walls has a sliding glass door offing the master suite private access to the 3 season porch. Additional master suite amenities include his-and-hers walk-in closets and a luxurious bathroom complete with walk-in shower, soaking tub, private toilet and dual vanities.
The secondary bedrooms fill the right side of the floor plan along with a powder bathroom. The secondary bedrooms share a jack-and-jill bathroom with dual vanities and compartmentalized toilet, oversized shower and a soaking tub.
