General Notes and specifications, Such As:
a) Designs Loads
d) Structural Steel
g) Other Misc. specs.
Front, Rear and Side Elevations @1/4” scale
Foundation plan (1/4” scale) indicating beam and column sizes along with lower level framing
Reinforced foundation and footing details
First & Second Floor plan (1/4” scale) includes all necessary framing information, window rough openings, beam sizes and framing details for specialized areas.
Stairs, sections, cabinet layouts, window flashing and miscellaneous details necessary for understanding of construction methods.
Roof plan (1/8”) indicating pitches and wall heights as well as truss profiles indicating hell heights and raised ceiling areas
Wall section indicating standard materials and detailing for typical wall construction.
a) Floor joists
b) Exterior wall framing
c) Wall heights
Roof framing is indicated as manufactured engineered roof trusses. Truss profiles are included.
New to plan buying?
Triple gables and a brick & stone facade decorate the exterior of this one level home. Angled stairs are an intricate part of the design, adding a beautiful element to the entry. Vaulted ceilings, sloping to 10', in the Great Room add to the drama and the rear wall with dual windows flanking the fireplace is a breathtaking focal point. The Dining area offers access to a covered rear porch and showcases a raised center ceiling height of 9'9". The open kitchen is defined by a large island with seating, space is allotted for a 6 burner stove, a double oven and a walk-in pantry makes this a chef's delight.The Laundry Room, Mud Room and closet offer a buffer from the garage to the home. Three bedrooms include a Master Suite that pampers the homeowner with the luxury of a raised 10' ceiling and a bath with double bowl vanity, stand alone tub and a shower enclosure, commode room and walk-in closet. A full unfinished basement is the foundation included with this plan.
